Light and Thin, Film-based Touch Screens with Cover Glass
DUS-F
SERIES
Standard Film Model
- Capacitive
- Projected Type
- ITO Film
- Two-layer Film Structure
- Multi-Touch
- Gloved-Hand Operation
- Gesture Operation
- Tempered glass
7w
10.1w
10.4
10.4
12.1
12.1w
15
15.6w
18.5w
21.5w
7w
10.1w
10.4
10.4
12.1
12.1w
15
15.6w
18.5w
21.5w
Controller
FILM SENSOR CG-PCAP
Film-based Touchscreens with Cover Glass
Cover glass added on standard film/film touchscreen models featuring thinness and lightness. Film/film touch sensor is light and thin even with cover glass, and fit to limited space in chassis design.
Specification
SPEC
| Size |
Total Thickness * |
Dimensions * | Active Area * | Product Number | controller |
|---|---|---|---|---|---|
| -7w- | 1.1 |
188 x 133 |
152.4 x 91.44 |
DUS-F070WA060A1A |
DUS1200-02-F070W001 |
| -7w- | 1.8 |
183.1 x 132 |
152.4 x 91.44 |
DUS-F070WA060A2A |
DUS1200-02-F070W002 |
| -10.1w- | 1.1 |
255 x 171.7 |
216.96 x 135.6 |
DUS-F101WA060A1A |
DUS1200-02-F101W001 |
| -10.1w- | 1.8 |
255 x 171.7 |
216.96 x 135.6 |
DUS-F101WA060A2A |
DUS1200-02-F101W002 |
| -10.1w- | 1.8 |
TBD x TBD |
TBD x TBD |
DUS-F101WA060A2A/WS |
DUS1200-02-F101WWS002 |
| -10.4- | 1.1 |
272 x 216 |
211.2 x 158.4 |
DUS-F104A060B1A |
DUS2200A-02-F104001 |
| -10.4- | 1.8 |
246.6 x 198.7 |
211.2 x 158.4 |
DUS-F104A060B2A |
DUS2200A-02-F104002 |
| -12.1- | 1.1 |
308 x 242 |
246 x 184.5 |
DUS-F121A060B1A |
DUS2200A-02-F121001 |
| -12.1- | 1.8 |
283.6 x 227 |
246 x 184.5 |
DUS-F121A060B2A |
DUS2200A-02-F121002 |
| -12.1w- | 1.1 |
299.5 x 214.6 |
261.2 x 163.2 |
DUS-F121WA060B1A |
DUS2200A-02-F121W001 |
| -12.1w- | 1.8 |
299.5 x 214.6 |
261.2 x 163.2 |
DUS-F121WA060B2A |
DUS2200A-02-F121W002 |
| -15- | 1.1 |
393 x 317 |
304.2 x 228.1 |
DUS-F150A060B1A |
DUS2200A-02-F121W001 |
| -15- | 1.8 |
344.4 x 273.2 |
304.2 x 228.1 |
DUS-F150A060B2A |
DUS2200A-02-F121W002 |
| -15.6w- | 1.1 |
386.2 x 241.4 |
344.3 x 193.6 |
DUS-F156WA060A1A |
DUS3200-02-F156W001 |
| -15.6w- | 1.8 |
386.2 x 241.4 |
344.3 x 193.6 |
DUS-F156WA060A2A |
DUS3200-02-F156W002 |
| -18.5w- | 1.1 |
456.9 x 289.5 |
409.8 x 230.4 |
DUS-F185WA060A1A |
DUS3200-02-F185W001 |
| -18.5w- | 1.8 |
456.9 x 289.5 |
409.8 x 230.4 |
DUS-F185WA060A2A |
DUS3200-02-F185W002 |
| -21.5w- | 1.1 |
526.4 x 330.3 |
476.7 x 268.1 |
DUS-F215WA060A1A |
DUS3200-02-F215W001 |
| -21.5w- | 1.8 |
526.4 x 330.3 |
476.7 x 268.1 |
DUS-F215WA060A2A |
DUS3200-02-F215W002 |
